Name: JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JZP-10.5-SC-SC1
Availability: InStock

خونه > محصولات > ضربه گیر لاستیکی >

JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation

10Hz to 100Hz Frequency Range Rubber Shock Absorber,-55 to +120 Working Temperature Vibration Isolator,Horizontal/Vertical Installation Passive Vibration Isolator

-55 to +120 Working Temperature Vibration Isolator

Horizontal/Vertical Installation Passive Vibration Isolator

محل منبع:

چین

نام تجاری:

Hoan

شماره مدل:

JZP-10.5-SC-SC1

با ما تماس بگیرید

درخواست نقل قول

JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation

جزئیات محصول

قطر:

0.25-2 اینچ

نشان:

انزوای ارتعاش

لوازم:

خالص

عرض:

50 میلی متر

عمل:

ضد شوک

صدور گواهینامه:

ISO 9001

نوع نصب:

افقی/عمودی

جهت گیری:

عمودی

دامنه فرکانس ارتعاش:

10 هرتز تا 100 هرتز

دما در حال کار:

: -55 ~ +120

OEM:

بله

نوع جداسازی ارتعاش:

منفعل

برجسته کردن:

10Hz to 100Hz Frequency Range Rubber Shock Absorber,-55 to +120 Working Temperature Vibration Isolator,Horizontal/Vertical Installation Passive Vibration Isolator

-55 to +120 Working Temperature Vibration Isolator

Horizontal/Vertical Installation Passive Vibration Isolator

شرایط پرداخت و حمل و نقل

مقدار حداقل تعداد سفارش

شرایط پرداخت

L/C ، D/A ، D/P ، T/T ، Western Union ، MoneyGram

محصولات مرتبط

JZP-13.5-SC-SC1 Rubber Shock Absorber with Damping Ratio 0.5 1 Year Warranty and 60mm Length for Sustainable Manufacturing

بهترین قیمت رو بدست بیار

JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation

بهترین قیمت رو بدست بیار

JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery

بهترین قیمت رو بدست بیار

JZP-7.5-SC-SC1 Friction Damping Vibration Isolator with Up to 90% Vibration Isolation M5 Mounting Thread Size and 50N/mm Axial Stiffness

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

86-29-88292913

حالا تماس بگیرید

توضیحات محصول

JZP-10.5-SC-SC1 Redefining Precision Equipment Stability with Xi'an Hoan Microwave's Rubber Shock Absorber

JZP-SC-SC1 Series

At the frontier of nanoscale science exploration, laboratory environment stability is essential for experimental success. The JZP-sc-sc1 series vibration isolators from Xi'an Hoan Microwave provide extreme stability for high-sensitivity instruments.

Key Advantages

Passive mechanical design ensures absolute reliability with zero energy consumption
No external power required, eliminating risks from power fluctuations
Superior attenuation of structural low-frequency vibrations (1-100Hz range)
Eliminates creep and aging issues of traditional vibration isolation materials
Maintains long-term stable stiffness and damping performance

Ideal Applications

Optical platforms, atomic force microscopes (AFMs), gene sequencers, and other high-precision instruments requiring vibration-free environments.

Dimension Parameters

Model	D (mm)	H±1 (mm)	h (mm)	A±0.2 (mm)	B (mm)	d	d2	R	b (mm)
JZP-SC-SC1	60	36	24.5	50	60	M5	∅5.5	5	28

Technical Parameters

Model	Nominal Load (KG)	Static Displacement (mm)	Working Temperature (℃)	Resonance Frequency (Hz)	Impact Test	Limited Period
JMZ-3.2-SC-SC1	3.2	≤0.3	-45～+65	41.5±5	100g 12 times	8
JMZ-4.2-SC-SC1	4.2	Same as above
JMZ-5.2-SC-SC1	5.2	Same as above
JMZ-6.0-SC-SC1	6.0	Same as above
JMZ-7.0-SC-SC1	7.0	Same as above
JZP-7.5-SC-SC1	7.5	Same as above
JZP-9.0-SC-SC1	9.0	Same as above
JZP-10.5-SC-SC1	10.5	Same as above
JZP-13.5-SC-SC1	13.5	Same as above
JZP-15-SC-SC1	15	Same as above
